Non-Rocket Spacelaunch – Space Elevator

Today I’m starting a new series of articles about non-rocket spacelaunch methods. Non-rocket spacelaunch is the idea of reaching outer space without the use of conventional chemical rockets, which is currently the only method in use.

Why non-rocket spacelaunch? Because the current chemical rockets are really expensive. In order to further explore outer space and establish a permanent human presence in space we need more cost efficient spacelaunch methods. In fact, present-day launch costs are in the range of $10,000 to $25,000 per kilogram from Earth to low Earth orbit. This is much too expensive for any serious space colonization efforts. Therefore we need to move beyond conventional chemical rockets and research alternative spacelaunch methods.

Each issue of this series will focus on one non-rocket spacelaunch method, starting with the space elevator.

What is a space elevator?

A space elevator is a proposed structure designed to transport material from a celestial body’s surface into space. Such a structure for planet Earth would consist of a cable anchored to the Earth’s surface, reaching into space. By attaching a counterweight at the end or by further extending the cable for the same purpose, inertia would ensure that the gravitational pull on the lower sections is counteracted, thus allowing the elevator to remain in geostationary orbit. Once beyond the gravitational midpoint, carriages would be accelerated further by the planet’s rotation. (The diagram below is not to scale.)

Space elevator structural diagram

The concept was first proposed in 1895 by Konstantin Tsiolkovsky, a Russian-born scientist of Polish descent. He imagined a free-standing tower reaching from the surface of Earth to geostationary orbit. The whole structure would have been 35,790 kilometers tall. Modern space elevator concepts consist of a cable rather than a free-standing tower to reduce the weight of the structure.

Base station of a space elevator

A base station is where the space elevator cable would be anchored. There are two main types of base station designs for the space elevator: stationary and mobile. Stationary platforms would generally be located in high-altitude locations, such as on top of mountains, or even potentially on high towers. Mobile stations would typically be large oceangoing vessels.

Space Elevator AnchorA seagoing base station would also act as a deep-water seaport.
Image Credit & Copyright: Liftport

Mobile platforms have the advantage of being able to maneuver to avoid hazards such as high winds, storms, and space debris. While stationary platforms don’t have these advantages, they would have access to cheaper and more reliable power sources, and require a shorter cable. While the decrease in cable length may seem minimal (no more than a few kilometers), the cable thickness could be reduced over its entire length, significantly reducing the total weight of the whole structure.

Space elevator cable

A space elevator cable must carry its own weight as well as the additional weight of the climbers. The required strength of the cable will vary along its length, since at various points it has to carry the weight of the cable below, or provide a centripetal force to retain the cable and counterweight above. Unfortunately conventional materials such as titanium, steel or aluminium alloys are not strong enough for the task.

Carbon nanotube animationCarbon nanotube animation

Currently the best candidate material are carbon nanotubes, though other materials have been proposed such as kevlar, graphene ribbons, quartz fibers, fibreglass and carbon/graphite fibre. Carbon nanotubes are the strongest material of them all, but unfortunately current technology allows growing tubes up to a few tens of centimeters only. Unless this technology is improved or a better material is invented the building of an Earth space elevator will not be possible for the foreseeable future. However this does not exclude the possibility of building space elevators on other celestial bodies with lower gravity such as the Moon or Mars. In fact the technology required for such a feat exists since the late 1970s. [Reference: Hans Moravec]

Space elevator climbers

A climber is a vehicle that climbs up the space elevator cable. Most climbers designs propose to use pairs of rollers to hold the cable with friction. Climbers must be spaced at optimal timings so as to minimize cable stress and oscillations and to maximize throughput. Lighter climbers can be sent up more often, with several going up at the same time. This increases throughput somewhat, but lowers the mass of each individual payload.

Space elevator climberSpace elevator climber. Image Credit & Copyright: Liftport

Another design constraint will be the ascending speed of the climbers. As geosynchronous orbit is at 35,786 km, assuming a climber can reach the speed of a very fast car or train of 300 km/h it will take about 5 days to reach geosynchronous orbit. If this speed limit cannot be exceeded, the space elevator would be mostly for lifting cargo, while passengers will probably choose another spacelaunch method. However future technological breakthroughs could change this.

The climbers will require electrical power. All proposals to get that energy to the climber fall into 3 categories:

  • Transfer the energy to the climber through wireless energy transfer while it is climbing.
  • Transfer the energy to the climber through some material structure while it is climbing.
  • Store the energy in the climber before it starts—this requires an extremely high specific energy.

The first method is laser power beaming, using megawatt powered free electron or solid state lasers in combination with adaptive mirrors approximately 10 meters wide and a photovoltaic array on the climber tuned to the laser frequency for efficiency.

The second method is to add a second cable and use the conductivity of carbon nanotubes to provide power. This method was proposed by Yoshio Aoki, a professor of precision machinery engineering at Nihon University and director of the Japan Space Elevator Association.

For the third method, nuclear energy and solar power have been proposed. However generating enough energy to reach the top of the elevator in any reasonable time without weighing too much is probably not feasible.

A major obstacle for any climber design is the dissipation of the substantial amount of waste heat generated due to the less than perfect efficiency of any of the power methods, as well as the friction with the cable.

Space elevator counterweight

A space elevator needs to be balanced with some sort of counterweight so that it wouldn’t crash down on Earth. Three main solutions have been proposed to act as a counterweight:

  • A heavy, captured asteroid;
  • A space dock, space station or spaceport positioned past geostationary orbit;
  • An extension of the cable itself far beyond geostationary orbit.

Capturing an asteroid is no easy task, so the first solution is not as practical as it seems, even-though it would shorten the cable considerably.

A space dock, space station or spaceport positioned past geostationary orbit is in my opinion the best solution, as it would be both efficient and practical.

Extending the cable far beyond geostationary orbit is also a good idea since a payload that went to the end of the counterweight-cable would acquire considerable velocity relative to the Earth, allowing it to be launched into interplanetary space.

Safety issues and construction challenges

With a huge structure as the space elevator many things can go wrong. Therefore it should be made more redundant in order for it to be safer. Many other safety measures should also be taken. Part two of this article will focus on this issue more extensively.

Extraterrestrial elevators

Earth is not the only planet that could have a space elevator. Variants of the basic space elevator design could also be built on other celestial bodies in the solar system. Part three of this article will focus on this concept more extensively.

Space elevators in fiction

A fourth part to this article will list the occurrences of space elevators in works of fiction.
